Adhesion is Physics, Not Luck.
Synchronizing the Coefficient of Thermal Expansion (CTE) to eliminate shear stress at the oxide interface.
Porcelain Delamination & Late Fracture
Risk Addressed
Porcelain Delamination & Late Fracture
The primary cause of ceramic failure is thermal mismatch. If the metal contracts faster than the ceramic during cooling (High CTE), the ceramic is placed under compression. If it contracts slower (Low CTE), the ceramic cracks under tension. ValidTi alloys are engineered to lock into the 'Safe Compression Zone' of leading low-fusing ceramics.
Fig 1. Thermal Expansion Synchronization (25°C - 500°C). Cooling curve showing ValidTi overlapping with Standard Dental Porcelain.
Bonding Performance Data
| Parameter | ValidTi Standard | ISO 9693 Min. Requirement |
|---|---|---|
| CTE (25-500°C) | 9.7 ± 0.1 x 10⁻⁶/K | N/A (Must match ceramic) |
| Debonding Strength | > 35 MPa (3-Point Bend) | > 25 MPa |
| Surface Prep | Al₂O₃ 110µm @ 2-3 bar | Manufacturer Defined |
Verified Ceramic Systems
Noritake
CompatibleSuper Porcelain Ti
GC
CompatibleInitial Ti
Ivoclar
Requires AgentIPS Style
Vita
CompatibleTitankeramik
Technical Documentation / Bonding Vault
View ISO 9693 Test Report in Compliance Vault
